PA 200X6 Six Channel Power Amplifier
The Eight Audio PA 200X6 is engineered to deliver clean, powerful, and highly controlled amplification across five channels, making it an ideal solution for immersive multi-channel home theater systems. Built with advanced ICEpower® Class-D technology featuring HCOM (Hybrid Controlled Oscillation Modulation), the PA 200X6 ensures exceptional clarity, efficiency, and dynamic performance.
ICEpower® Class-D with HCOM Technology
Clean Power with Precision Control
At the core of the PA 200X6 lies ICEpower® Class-D amplification with HCOM, delivering highly efficient and low-distortion performance.
Key Advantages:
- Ultra-low distortion and noise
- High efficiency with minimal heat generation
- Fast transient response for dynamic sound
- Stable and consistent output across all channels
This results in clean, detailed, and impactful sound, ideal for both movies and music.
True Mono Channel Design
Independent Power for Each Channel
The PA 200X6 features a true mono design, where each channel is powered independently with its own dedicated power supply.
Benefits:
- Separate power supplies for each channel
- Minimal cross-talk and interference
- Improved channel separation
- Enhanced soundstage and imaging
- Consistent performance under high load
This architecture ensures that every channel performs with precision and without compromise.
Input Flexibility
Professional & Consumer Connectivity
Each channel of the PA 200X6 offers both balanced XLR and unbalanced RCA inputs, providing flexibility for different system configurations.
Advantages:
- Compatible with AV processors and receivers
- Reduced noise with balanced XLR connections
- Easy integration into any home theater setup
- Flexibility for professional and home use
Key Highlights
- 5-channel high-performance power amplifier
- ICEpower® Class-D with HCOM technology
- True mono design with independent power supplies
- Minimal cross-talk and superior channel separation
- Balanced XLR and unbalanced RCA inputs
- High efficiency with low heat output
- Ideal for home theater and multi-channel audio systems
Details & Specifications of PA 200X6
| System Type | 6-Channel Mono Amplifier |
| Amplification type | Class D with Hybrid feedback Controlled Oscillation Modulator (HCOM) - ICEpower® |
| Frequency Response | 35 - 22000 Hz +/- 3db |
| Minimum Load impedance | 2.7 Ω |
| Output Power (RMS) - Three channels driven |
4Ω - 210W 8Ω - 117W 2.7Ω - 300W |
| THD+N |
1% @ 117W in 8Ω |
| Dynamic range | 110 dB S/N, (A-weighted at 300 W, 4 Ω) |
| Application | Professional Home Cinema Amplifier |
| Input Connectors | Balanced - XLR & Unbalanced - RCA |
| Output Connectors | Copper base Gold plated 5way binding posts |
| Trigger & Auto on / off | 12V DC Trigger Input / Loop Out |
| Mains Power | 230V 50Hz (IEC Connector) |
| Product Dimensions |
Height - 170mm Width - 450mm Depth - 385mm (410mm With Connectors) |
| Net weight | 9 Kgs |
